3 Series E36 M coupe (S54) COUPE
51 13 ...
Replacing bracket for roof luggage rack at left
or right (Z3 coupé, M coupé)
Removing trim strip on roof frame at left or right,
refer to 51 13 280.
Remove body sealing compound (1) with special tool 00 9 322
and unfasten threaded pin (2).
Installation:
Threaded pin may not be wetted with screw securing
adhesive on screw-in thread (1).
Before installing threaded pin, protect body against corrosion
(e.g. apply zinc dust paint).
Tightening torque,
refer to Technical Data 51 13 1AZ.
Apply body sealing compound (1) (Terostat 9320, Sourcing
Reference BMW Parts Service).
After hardening time of body sealing compound (1) (refer to
manufacturer's specifications), paint over body sealing compound
(1) and threaded pin (2) with paint pencil of corresponding car
colour.
