3 Series E36 M roadst (S50) ROADST
5.
Disconnect the installed SDR module and remove.
6.
Press body sealing compound (1) onto the underside of new SDR module (2).
Figure 2
7.
Plug connector (2) onto SDR module (1), as shown in Fig. 3. Press module onto
transmission tunnel.
Figure 3
8.
Refit any parts which have been removed.
9.
Delete "anti-theft alarm counter".
Parts:
Description
Part number
Quantity
Module for interior radar
protection
61 35 6 917 950
1
Reimbursement:
Material and labour costs incurred can be claimed through the usual warranty channels
subject to current warranty terms.
Defect code
65 75 95 40 00
SI False anti-theft alarm by radar-operated passenger compartment sensor Z3 roadste
