3 Series E36 M roadst (S50) ROADST
11 24 571
Replacing all conrod bearings (S50) (pistons
removed)
Special tools required:
•
00 2 590
•
00 9 120
•
11 2 110
Install new bearing shells.
Insert one red and one blue bearing shell for each conrod.
Important!
Note grinding stages on crankshaft.
Install piston.
Check conrod bearing clearance.
Piston in BDC position.
Fit special tool 00 2 590 (Plastigage Type PG 1) to the oil-
free crankshaft.
Fit bearing caps so that pair numbers match up.
RA Replacing all conrod bearings (S50) (pistons removed)
BMW AG - TIS
09.02.2013 19:03
Issue status (12/2007) Valid only until next DVD is issued
