3 Series E36 M roadst (S52) ROADST
Version with electrohydraulic/semi-automatic convertible top
operation only:
Release retaining clip (1) and pull off downward.
Pry out hydraulic cylinder (2) inward with special tool 00 9 319.
Stow convertible top in its compartment.
Version with electrohydraulic/semi-automatic convertible top
operation only:
Unlock connector (1) and remove.
Unclip finisher strip (1) until guide (2) leaves the mucket (3) and
remove the mucket.
Installation:
Insert mucket (3) in the convertible top compartment seal (4)
(leaks).
Unfasten left/right screw (1) and nut (2).
Remove screw (1) with washer (3) and shim (4).
Note:
Note down number of shims (4).
RA Removing and installing complete convertible top (Z3 Roadster, M Roadster)
