3 Series E46 316Ci (N45) COUPE
52 13 000
Removing and installing left or right front seat
(normal/manual)
Necessary preliminary tasks:
•
Remove head restraint
•
Adjust front seat as far forward and upward as possible.
Warning!
Read and comply with safety regulations for handling airbag
modules and pyrotechnical belt tensioners.
Improper handling can lead to triggering of the pyrotechnical
seat belt tensioner or side airbag, resulting in injuries.
Switch off ignition.
Saloon only:
Release seatbelt screw (1) and feed out seatbelt strap (2).
Tightening torque 72 11 1AZ
.
All:
Release screws (1) at rear.
Tightening torque 52 10 1AZ.
Installation:
Replace screws.
Move front seat as far back as possible.
RA Removing and installing left or right front seat (normal/manual)
BMW AG - TIS
18.01.2013 23:04
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
