3 Series E46 316Ci (N45) COUPE
52 14 ...
Removing and installing/replacing guide for
front left or right head restraint
(normal/electric)
Necessary preliminary tasks:
•
Remove rear panel on front seat backrest
•
Remove head restraint
Guide for head restraint with pushbutton:
Release catches (1) and (2) and slide guide (3) upwards.
Pull guide (1) out of backrest (2).
RA Removing and installing/replacing guide for front left or right head restraint (
BMW AG - TIS
18.01.2013 23:11
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
