3 Series E46 316ti (N42) COMP
31 00 Front axle - ride height E46 COMP up to 03/03
Ride level in normal position (attach tape measure to rim
flange at bottom middle and measure to lower edge of
wheel arch)
Deviation from nominal value for all wheels together
max. mm
10
Series
15" rim
mm
±
10
563
16" rim
mm
±
10
576
17" rim
mm
±
10
591
18" rim
mm
±
10
604
TD Front axle - ride height E46 / COMP / up to 03/03
