3 Series E46 318Ci (N46) COUPE
51 32 170
Removing and installing/replacing front left or
right door window (Coupé, Convertible)
Necessary preliminary tasks:
•
Remove sound insulation from front door
•
Remove window cavity cover strip on inside of front door
Open door window glass (1) by distance (A).
A = approx. 80 mm
Disconnect plug connection (1) from power window motor (2)
(risk of trapping).
Installation:
Convertible from build date 09/2003:
Carry out normalization.
Note:
Screw has left-hand thread; turn clockwise to release.
Release bolt (1).
Tightening torque 51 32 2AZ
.
Installation:
Insert door window glass in guide rail (2).
RA Removing and installing/replacing front left or right door window (Coupé, Conver
