3 Series E46 318ti (N42) COMP
Connect compressed air hose (1) to pressure gauge.
Immerse cylinder head in a water bath. Inspection
pressure 4.5 bar.
Check cylinder head for escaping air (cracks).
Note:
If necessary, add cleaning agent to water bath.
RA Leak-testing cylinder head (N40/N42/N45/N46)
