3 Series E46 318ti (N42) COMP
22 11 011
Replacing left engine mount (N42 / N40 / N45 /
N46)
Necessary preliminary tasks:
-
Release left engine mount from above
-
Remove intake air manifold
-
Secure engine with special tool
-
Remove front underbody protection
-
Remove reinforcement plate on front axle support
-
Remove engine support arm from engine block
-
Release screw connection for engine mount at bottom left
-
Tilt engine mount out to one side and remove
RA Replacing left engine mount (N42 / N40 / N45 / N46)
