22 11 100

Replacing right engine support arm (N42 /
N40 / N45 / N46)

Remove right engine mount.

Remove grounding strap from engine support arm.

Installation:

Clean contact surfaces to ensure a safe ground connection.

Remove engine support arm from engine.

RA  Replacing right engine support arm (N42 / N40 / N45 / N46)

BMW AG - TIS

12.02.2013  03:34

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 1 -
