3 Series E46 318ti (N42) COMP
Push torque converter through radial shaft seal onto transmission
shaft as far as it will go.
Press torque converter by hand into converter housing. Turn in so
doing until opening of converter hub engages in driver of pump
impeller. Torque converter must noticeably slide inwards.
Determine distance between contact surface and surface (1) of
tapped hole in torque converter with special tool 00 2 550 .
Torque converter is correctly installed when measured value is
greater than 30 mm.
RA Replacing radial shaft seal for torque converter (A5S 360R / 390R, A4S 200R)
BMW AG - TIS
12.02.2013 04:00
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 3 -
