3 Series E46 318ti (N42) COMP
Remove screws (1).
Remove vane pump (2) from water pump (3) and remove
towards bottom/top.
Installation:
Replace O-ring on water pump connecting piece and coat with
coolant.
Align vane pump shaft (2) to mounting on water pump (3).
Important!
Make sure connector is correctly seated in crankcase.
Connector must not jam when inserted!
After installation:
•
Add coolant and hydraulic fluid
•
Venting cooling system and checking for water leaks
•
Bleeding hydraulic system
•
Check pipe connections for leaks
RA Removing and installing/replacing power steering vane pump (N4x)
