3 Series E46 318ti (N42) COMP
Unhook cables from clip (1).
Version with speaker (2) also:
Disconnect plug connection below on speaker and expose cable.
Release screw (3) and if necessary remove speaker (2) and
retaining plate (4).
Partly lever out seal (5) at front and release screws (6).
Installation:
Tightening torque 51 16 1AZ.
Check function.
Remove rearview mirror (1) with sound insulation underneath and
feed out cable (2).
RA Removing and installing/replacing rearview mirror on left or right front door (c
