3 Series E46 318ti (N42) COMP
51 32 211
Replacing rubber guide for front left or right
door window glass (compact)
Remove mirror on front door.
Remove trim on window frame of front door.
Remove cover on inside of door window frame.
Open complete door window glass.
If necessary, remove sound insulation (1).
Remove complete rubber guide (1) from front door (2).
Installation:
Coat rubber guide (1) with water prior to installation.
Insert rubber guide at front/bottom in window guide channel.
Installation:
Guide (1) and mount (2) on rubber guide (3) must not be
damaged.
RA Replacing rubber guide for front left or right door window glass (compact)
