3 Series E46 318ti (N42) COMP
Caution!
Replace damaged screws and nuts.
Installation:
Screws (3) are longer than the other screws.
Unclip clips (1) of door trim panel with special tool 00 9 317
(trim panel wedge).
Carefully unclip door trim panel (1) at top with special tool
00 9 317 (trim panel wedge) from clips (2).
Feed door trim panel (1) out of unlocking knob (3).
Lever out cable clip (3) and (4).
Caution!
If necessary, replace faulty cable clip (3) and (4) otherwise
function of side airbag will be jeopardized.
Feed lines (5) out of opening (6).
Version with memory for electric seat adjustment:
If necessary, disconnect plug connection at control unit.
Version with additional speaker:
If necessary, disconnect plug connection (1) on supplementary
speaker (2) and remove door trim panel.
RA Removing and installing left or right front door trim panel (compact)
