3 Series E46 318ti (N42) COMP
Unclip release mechanism towards top.
Note:
On both sides on passenger seat.
Installation:
Cable covering must point out a little over covering mount.
Installation:
-
Release screw (1) and remove seat back towards top.
-
Insert adjusting tool (2) in seat back and secure with
screw (1).
-
Clip cable on both sides onto mounting lug (3).
-
Slide catch lug (4) into cable end clip until there is no
cable play.
-
Lock catch by pushing up retaining ring (5).
-
Unclip cable, remove adjusting element (2), install seat
backrest.
Note:
Catch can no longer be released when retaining ring has snapped
into place.
