3 Series E46 318ti (N42) COMP
52 15 011
Removing and installing/replacing Bowden
cable for rear compartment entrance aid
Necessary preliminary tasks:
•
Remove seat
•
Remove rear panel
•
Remove outer cover
•
Remove inner cover
Lay seat on seat surface/backrest or left seat side.
Unhook and remove springs (1).
Remove retainers (2).
Release screw (1) of cable mount (2).
Detach cable mount (2) and cable eye (3) from shaft.
Feed cable out of holder (4).
Disconnect spring (1).
Unclip sleeve (2) of Bowden cable from guide.
Feed out cable (3).
RA Removing and installing/replacing Bowden cable for rear compartment entrance aid
