3 Series E46 318ti (N42) COMP
34 11 Front Wheel Brakes E46 COMP
Wear warning from residual lining thickness
mm
3.0
Brake disc minimum thickness
(MIN TH) is stamped in brake disc shell
Models: All
mm
20.4
Max. machining limit per friction ring side
(M models must not be machined)
mm
0.8
Different thicknesses on brake linings
Max. mm
0.01
Surface roughness of braking surfaces (precision-turned)
Ra
µ
0.5...3.5
Brake disc diameter
Models: 316ti, 318ti,
mm
286
Brake disc diameter
Models: 320td, 325ti
mm
300
TD Front Wheel Brakes E46 / COMP
BMW AG - TIS
12.02.2013 17:57
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
