3 Series E46 330i (M54) TOUR
Illustrations show E46.
Pull lock (1) upwards and detach heat exchanger towards rear.
Installation:
Press lock (1) downwards before pushing on heat exchanger.
The lock must snap audibly into place when the heat exchanger is
forced on.
Check sealing rings (1), replace if necessary.
Add final details to vehicle.
RA Removing and installing/replacing heat exchanger for automatic transmission
