3 Series E46 330i (M54) TOUR
Installation:
Press mount in area of retaining lugs into selector arm until it
audibly snaps into place.
Installation:
Grease selector lever ball.
Grease, refer to BMW Service Operating Fluids.
Install selector lever in selector arm.
Align mount:
-
Arrows on mount in longitudinal axis of vehicle.
-
Retaining lugs of mount, transverse to direction of travel.
RA Removing and installing shift lever
BMW AG - TIS
15.02.2013 21:08
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 4 -
