3 Series E46 330i (M54) TOUR
Unfasten bolt from automatic safety belt tensioner of center safety
belt.
Installation:
Tightening Torque,
refer to Technical Data 72 11 9AZ.
Installation:
Observe coding!
Lug (1) of backrest must lie in recess (2) of center automatic
safety belt tensioner for fixing.
Remove Bowden cable from brackets in backrest and take out
automatic seat belt tensioner.
Installation:
Bowden cable must rest in backrest brackets and pass
through bore hole of backrest to backrest lock.
1.
Bracket for Bowden cable in backrest
2.
Bowden cable
3.
Bore hole in backrest at backrest lock
4.
Backrest
RA Removing and installing / replacing rear center safety belt
