3 Series E46 M3 CSL (S54) COUPE
11 62 140
Removing and installing, sealing/replacing
both exhaust manifolds (S54)
E46 only
Remove microfilter.
Open cable duct on lower section of microfilter housing (2) and
feed out cable(s).
Release screws (1) and remove lower section of microfilter
housing (2).
E46 only
Remove expansion rivets. Remove air duct (1).
Remove hose (1) for engine vent.
Remove sealing cap (2).
Remove ignition coil cover.
Note:
The plug housings of the oxygen sensors for cylinders 1 to 3
and 4 to 6 are different.
Unclip plug housing (1) from mounting.
Disconnect plug connections of oxygen sensors.
