3 Series E46 M3 CSL (S54) COUPE
Caution!
The section "Removing and installing reinforcement plate"
contains important installation instructions.
Remove reinforcement plate.
Remove engine underguard at front.
Remove catalytic converter and intermediate pipes.
Remove heat shield (1).
Remove heat shield (1).
Remove bracket for underbody protection at rear.
RA Removing and installing transmission (S6S 420G)
