3 Series E46 M3 CSL (S54) COUPE
Adjust gap dimensions and position of trunk lid relative to the
other fittings on the body,
refer to 41 00 ...
Tighten left and right screws (1 and 2).
-
Adjust lower section of trunk lid lock:
(Screws of rear lid lock lower section released until adjustment is
possible)
Close trunk lid, holding down the lock button to prevent the trunk
lid lock from engaging.
This enables lower section of trunk lid lock to adjust itself correctly.
Adjust gap measurements and position of rear lid (height) relative
to other fittings on body,
refer to 41 00 ...
Tighten screws on lower section of trunk lid lock.
RA Adjusting trunk lid to fit
