3 Series E46 M3 CSL (S54) COUPE
Check adjustment of trunk lid and trunk lid lock, repeating
adjustment if necessary.
Screw in detent buffer until left and right sides of trunk lid locate
against detent buffers when closed.
Caution!
Trunk lid must not protrude above side panels otherwise
height adjustment can be distorted!
Gently twist ejector in detent buffers to right with Phillips
screwdriver. This unlocks the detent buffers, enabling ejector to
emerge.
-
Adjustment of stop screw of rear lid hinge:
Stop screw (1) set to measurement (A).
Measurement (A) = 10 mm.
RA Adjusting trunk lid to fit
