3 Series E46 M3 CSL (S54) COUPE
51 13 286
Replacing bracket for roof luggage rack on
left or right
Special tools required:
•
00 9 322
Necessary preliminary tasks:
•
Remove trim strip from roof frame
Remove body sealing compound (1) with special tool 00 9 322
and unfasten threaded pin (2).
Note:
Threaded pin is designed as Torx from E87 model series.
Installation:
Threaded pin may not be wetted with screw securing adhesive on
screw-in thread (1).
Before installing threaded pin, protect body against corrosion (e.g.
apply zinc dust paint).
Tightening torque 51 13 1AZ
.
RA Replacing bracket for roof luggage rack on left or right
