3 Series E90 318d (N47) SAL
Important!
A small amount of engine oil emerges when oil pressure
switch is removed.
Have a cleaning cloth ready.
Unlock connector and remove.
Release oil pressure switch.
Installation:
Replace sealing ring.
Tightening torque 12 61 1AZ
.
Reassemble car and set in horizontal position.
Start engine and run at idle until oil pressure warning lamp goes
out.
Switch off engine. Wait approx. 5 minutes and then check engine
oil level.
Top up engine oil if necessary.
RA Removing and installing/replacing oil pressure switch (N47)
