3 Series E90 318d (N47) SAL
Detaching cover and padding:
•
Release all retainers in marked area
•
Remove cover from padding
•
Remove remaining retainers from cover and padding
Installation:
Insert new retainers with special tool 52 0 050 .
In so doing, enclose wire in padding and trim wire of cover.
Only when replacing seat cover for E90 with build date up to
03/06:
Pull liner off foam strip (1).
Stick on foam strip flush with top edge of padding.
Short protruding foam strip.
Replacing cover:
•
Remove all trim wires from cover
•
If necessary, cut pockets in new cover for trim wires
•
Push trim wires into cover pockets
RA Replacing right backrest cover for rear seat
