3 Series E90 320i (N46T) SAL
Installation:
Check adapter sleeve (1) for damage and correct installation
position.
Installation:
The position of the adapter sleeve is identified by a notch (1) in
the flywheel.
Installation:
Replace screws.
Secure flywheel screws with special tool 11 4 180 .
Tightening torque, 11 22 1AZ
.
Remove all special tools.
Assemble engine.
RA Removing and installing or replacing flywheel (N46T)
