3 Series E90 330i (N52) SAL
Assemble cross member 00 0 200 with special tools 00 0 202 ,
00 0 204 , 00 0 208 .
Note:
Use towing hook (72 15 8 108 670).
Important!
Avoid a change of engine position in the transverse or
longitudinal direction.
Always make sure there is sufficient clearance between the
engine (or its attachment parts) and the body.
Important!
Risk of damage!
With the aid of an assistant and the supports (2), place cross
member 00 0 200 on the screw connections of the side
panels.
Screw in towing hook (1) and tighten down to approx. 30 Nm.
Secure special tool 11 0 000 to spindle 00 0 202 .
Fit suitable chains to special tool 11 0 000 and attach to towing
hook (1) or engine lifting eye.
RA Securing engine in installation position (N52)
