1 RA Removing And Installing_replacing High-pressure Pump (M57TU _ M57T2)|Page 494 > < 1 RA Removing And Installing_replacing High-pressure Pump (M57TU _ M57T2)|Page 492

3 Series E90 335d (M57T2) SAL

Page 3
background image

Screw special tool 13 5 192  into timing case cover.

Firmly screw special tool 13 5 191  without jack screw (1) into
sprocket wheel by hand.

Screw in jack screw (1) and pretension H.P. pump.

Unscrew nuts (1).

Note:

Illustrations show M47TU.

Tighten jack screw (1) until high-pressure pump is released from
pump impeller.

Important!

Special tools 13 5 191  and 13 5 192  must remain in
timing case for securing purposes and must not be removed
under any circumstances (risk of damage!).

Remove jack screw (1) to install high-pressure pump.

RA  Removing and installing/replacing high-pressure pump (M57TU / M57T2)
