3 Series E90 335i (N54) SAL
23 00 018
Removing and installing transmission (GS6-
53BZ) N54
Special tools required:
•
00 2 030
•
00 9 010
•
00 9 120
•
00 9 130
•
21 2 240
•
23 0 132
•
23 4 050
Important!
After completion of work, check gear oil level.
Use only the approved gear oil.
Failure to comply with this requirement will result in serious
damage to the manual transmission.
Important!
Aluminium screws/bolts must be replaced each time they are
released.
The end faces of aluminium screws/bolts are painted blue for
the purposes of reliable identification.
Jointing torque and angle of rotation must be observed
without fail (risk of damage).
Necessary preliminary tasks:
•
Disconnect battery
•
Remove front underbody protection
•
Remove rear underbody protection
•
Remove complete exhaust system
•
Remove heat shields
•
Support engine with lifter when removing transmission
RA Removing and installing transmission (GS6-53BZ) N54
BMW AG - TIS
22.02.2013 05:28
Issue status (12/2007) Valid only until next DVD is issued
