3 Series E91 325xi (N52) TOUR
Following special tools are required for disconnecting the plugs:
Secondary locking, all plugs:
Special tool 61 0 324
Primary locking for plugs X11001, X11002, X11004, X11005, X11006:
Special tool 61 0 316
Primary locking for plug X11007:
Special tool 61 0 317
Special tool for crimping contact:
Double flat spring contact:
Crimping tool special tool 61 0 202 (crimping tool) with special tool 61 0 230 (matrix)
From previous vehicle status up to 09/2005
After new vehicle status from 09/2005
From plug
Pin at position
After plug
Reconnect at position...
X11006
02
X11006
03
X11006
03
X11006
02
X11005
01
X11005
02
X11005
02
X11005
03
X11005
03
X11005
01
X11001
01
X11002
01
X11002
01
X11001
01
X11004
04
X11004
05
X11007
01
X11004
04 (new double flat spring
contact 8 377 731 and 8
377 733)
RA Replacing interior fuse box for cars before 09/2005 with one with a new build da
