3 Series E92 320i (N46T) COUPE
4-hole:
Screw special tool 11 9 232 with a screw (special tool
11 9 234 ) to crankshaft.
Note:
Support sleeve (1) is supplied with crankshaft seal (2).
When crankshaft seal (2) is installed, only support sleeve (1)
may be used as a slip sleeve.
Crankshaft seal (2) has a groove on both left and right sides.
Important!
After installation, the grooves must be filled with sealing
compound.
Important!
The following text describes installation and sealing between
the engine block and crankshaft seal.
The engine block will not be leakproof at the outside of the
crankshaft seal if you fail to comply with the individual work
steps and the work sequence.
Note:
The required parts are available from the BMW Parts Service
(Electronic Parts Catalogue ETK).
Remove screw caps (1) from injector (2).
Screw on needle and insert plunger.
Injector (2) contains the sealing compound Loctite,
manufacturer's number 128357.
Bottle (3) contains the primer Loctite, manufacturer's
number 171000.
RA Replacing front crankshaft seal (N46T)
