3 Series E92 320i (N46T) COUPE
51 16 383
Removing and installing/replacing damper for
glovebox
Necessary preliminary tasks:
•
Remove glovebox with housing
Open glovebox.
Release clip (1).
Press catch (1) together and slide damper (2) in direction of
arrow.
Remove damper (2) in inward direction.
Installation:
Catch (1) and guide (2) on damper (3) must not be damaged or
missing.
RA Removing and installing/replacing damper for glovebox
