3 Series E92 320i (N46T) COUPE
Remove airbag module on passenger side.
Release screws (1).
Remove holder for airbag module on passenger side (2) from
instrument panel trim (3).
Unclip both side fresh-air grills (1) with special tool 00 9 340 in
direction of arrow from instrument panel trim (2).
Unclip cover for steering column opening (3) in direction of arrow
from instrument panel trim (2).
Remove all metal nuts (2) and clips (3) from instrument panel
trim (1).
RA Replacing instrument panel trim
