3 Series E92 320i (N46T) COUPE
64 53 515
Replacing desiccant insert for A/C system
Warning!
Risk of injury!
Refrigerant circuit is under high pressure!
Follow safety instructions for handling R 134a refrigerant .
Avoid contact with refrigerant and refrigerant oil.
Follow safety instructions for handling refrigerant oil.
Important!
Risk of damage!
Restart engine only when A/C system has been correctly
filled.
Read and comply with notes on replacing compressor.
Follow instructions for opening and replacing parts in
refrigerant circuit.
If A/C system is opened for more than 24 hours:
Replace desiccant insert for A/C system
Necessary preliminary tasks:
•
Drawing off, evacuating and filling the A/C system are not
included in the time value given for this work operation
•
Remove condenser
If necessary, pierce sticker over sealing cap (1).
Remove cap (1) from condenser (2).
Installation:
Tightening torque 64 53 12AZ
.
RA Replacing desiccant insert for A/C system
BMW AG - TIS
22.01.2013 19:25
Issue status (12/2007) Valid only until next DVD is issued
