3 Series E92 320i (N46T) COUPE
65 20 350
Removing and installing/replacing
suppression filter
Necessary preliminary tasks:
•
Remove panel for parcel shelf
Disconnect plug connection (1).
Release screw (2).
Remove suppression filter (3) from C-pillar.
Installation:
Fit suppression filter (1) so that screw (2) engages thread (3)
and locating pin (4) engages bore (5).
RA Removing and installing/replacing suppression filter
BMW AG - TIS
22.01.2013 19:33
Issue status (12/2007) Valid only until next DVD is issued
