3 Series E92 320i (N46T) COUPE
11 25 Pistons with Rings and Pins N46T B20 UL
Piston and pin are paired to each other - replace together
only.
Piston diameter at measuring point "A"
mm
10
Original (new dimension)
mm
83.996
±
0.015
Oversize (new dimension)
mm
84.246
±
0.015
Piston installation clearance (piston new)
mm
0.012 ... 0.033
Piston installation clearance (piston worn)
mm
0.020 ... 0.047
Permissible total wear tolerance between piston and
cylinder
(engine operated)
mm
0.150mm
±
TD Pistons with Rings and Pins N46T / B20 UL
