3 Series E92 320i (N46T) COUPE
33 00 Rear axle - ride height E92 / E93
Ride level height in normal position
(attach tape measure to bottom middle of rim flange and measure to lower
edge of wheel arch)
Tolerance ride height in
- normal position max.
±
10 mm
- design position max.
±
2 mm
Difference ride height between left/right in
- normal position 10 mm
- design position 2 mm
Series
16" rim
mm
568
17" rim
mm
583
18" rim
mm
596
19" rim
mm
608
Low-slung sport suspension
16" rim
mm
553
17" rim
mm
567
18" rim
mm
580
19" rim
mm
592
SPORT SUSPENSION US version
16" rim
mm
555
17" rim
mm
569
18" rim
mm
582
19" rim
mm
594
TD Rear axle - ride height E92, E93
