3 Series E92 320i (N46T) COUPE
18 20 Exhaust system suspension
Type
Thread
Tightening specification
Measure
1AZ Retaining plate to transmission
N45/N46
M8
21 Nm
2AZ Front pipe holder to retaining plate
N45/N46
M8
21 Nm
3AZ Clamp to catalytic converter carrier
N45/N46
M8
21 Nm
4AZ Rear muffler to body
N45/N46
M8
21 Nm
5AZ Connection, rear axle carrier bearing
cap to support plate
N45/N46
M8
21 Nm
6AZ Bracket, exhaust system, to rear
differential
N45/N46
M12
30 Nm
AZD Exhaust system suspension
BMW AG - TIS
22.01.2013 22:09
Issue status (12/2007) Valid only until next DVD is issued
