3 Series E92 328i (N51) COUPE
Important!
Different diameters at valve stem.
Valve dia. 5 mm: valve stem seal is red or brown.
Valve dia. 6 mm: valve stem seal is green or light green.
Installation:
Fit the mounting sleeves (plastic sleeves) supplied in the spare
part on the valve stem end
Lubricate mounting sleeve.
Press on valve stem seal by hand with special tool 11 6 380 as
far as it will go.
Assemble engine.
RA Replacing all valve stem seals (N51)
