3 Series E92 328i (N52K) COUPE
Installation:
Slide sleeve (1) over locking pin (2).
Make sure sleeve (1) is correctly engaged in cover housing (3).
Replacement:
Release screws (1).
Disengage emergency actuation pull strap (2) from retainer (5)
and remove towards front.
If necessary, unclip locking pin (3) in direction of arrow from
servodrive for tank filler flap (4).
RA Removing and installing / replacing servodrive for tank filler flap
