3 Series E92 328xi (N51) COUPE
16 14 010
Removing and installing/replacing fuel pump
(US vehicles with N51 engines)
Special tools required:
•
00 9 252
Important!
Ensure adequate ventilation in the place of work!
Ensure absolute cleanliness when working on the open fuel
tank.
Contaminants in the fuel tank can impair driving operation or
may even result in vehicle breakdown!
Necessary preliminary tasks:
•
Draw off fuel from fuel tank
•
Remove rear seat bench
Release screws (1) and remove cover (2) from right side of fuel
tank.
RA Removing and installing/replacing fuel pump (US vehicles with N51 engines)
BMW AG - TIS
04.02.2013 01:59
Issue status (12/2007) Valid only until next DVD is issued
