3 Series E92 328xi (N51) COUPE
11 13 Oil Pan
Type
Thread
Tightening specification
Measure
1AZ Oil drain plug
N51
M12 x 1.5
25 Nm
2AZ Oil pan on engine block
Aluminium oil sump
Aluminium screws/bolts are marked
with blue paint.
N51
M8x26
Replace screws
Thread repairs exclusively
with Al Helicoil
Jointing torque and angle
of rotation must be
observed without fail.
Jointing torque
8 Nm
Torque angle
60
°
3AZ Oil pan on engine block
Aluminium oil sump
Aluminium screws/bolts are marked
with blue paint.
N51
M8x92
M8x112
Replace screws
Thread repairs exclusively
with Al Helicoil
Jointing torque and angle
of rotation must be
observed without fail.
Jointing torque
8 Nm
Torque angle
180
°
5AZ Oil deflector to crankcase lower
section
Aluminium screws/bolts are marked
with blue paint.
N51
M6x20
Replace screws
Thread repairs exclusively
with Al Helicoil
Jointing torque and angle
of rotation must be
observed without fail.
Jointing torque
4 Nm
Torque angle
90
°
6AZ Oil pan on engine block
Sheet metal oil sump
Aluminium screws/bolts are marked
with blue paint.
N51
M8x24
Replace screws
Thread repairs exclusively
with Al Helicoil
Jointing torque and angle
of rotation must be
observed without fail.
Jointing torque
8 Nm
