11 28 V-ribbed belt with Tension and Deflection Element

Type

Thread

Tightening specification

Measure

1AZ  Belt tensioner to engine block

N51

M11x65

Thread repair is not

permitted

Jointing torque

25 Nm

Torque angle

90

°

2AZ  Deflection pulley to alternator

N51

M10x40

40 Nm

AZD  V-ribbed belt with Tension and Deflection Element

BMW AG - TIS

04.02.2013  20:02

Issue status (12/2007) Valid only until next DVD is issued
