3 Series E92 328xi (N51) COUPE
Jointing torque
100 Nm
Torque angle
90
°
4AZ Control arm to swivel bearing
E81, E82, E87,
E88, E90 /
REAR END,
E91 / REAR
END, E92 /
REAR END,
E93
M14
Replace nut
165 Nm
E90 / Four
Wheel Drive,
E91 / Four
Wheel Drive,
E92 / Four
Wheel Drive
M14
Replace nut
80 Nm
5AZ Compression strut to front axle
carrier
E90 / Four
Wheel Drive,
E91 / Four
Wheel Drive,
E92 / Four
Wheel Drive
M12
Replace nut
tighten in normal position
Jointing torque
68 Nm
Torque angle
90
°
6AZ Compression strut to guide joint
E90 / Four
Wheel Drive,
E91 / Four
Wheel Drive,
E92 / Four
Wheel Drive
M14
Replace nut
80 Nm
7AZ Guide joint to swivel bearing
E90 / Four
Wheel Drive,
E91 / Four
Wheel Drive,
E92 / Four
Wheel Drive
M10
Recut thread
Replace screws
60 Nm
AZD Control Arms and Struts
