Installation:

Adjust new part to fit with straightening attachment or universal
mount.

MAG-weld hinge in area (1).

RA  Replacing front left outer door pillar section

BMW AG - TIS

26.01.2013  00:38

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 3 -
