3 Series E93 330d (M57T2) CONVER
Detaching cover and padding:
•
Release all retainers in marked area.
•
Remove seat cover from padding
•
Remove remaining retainers from cover and padding
Installation:
Insert new retainer (2) with special tool 52 0 050 and bend
closed.
1.
Padding
2.
Retainer
3.
Trim wire in padding
4.
Trim wire in seat cover
5.
Seat cover
Replacing cover:
•
Pull all trim wires out of seat cover
•
If necessary, cut in take-up for trim wires of new cover
•
Push trim wires into new seat cover
RA Replacing seat cover for rear seat
